Application:
PVC: Food, medicine, electronics, tobacco, printing, packaging, textile
and other production lines belt.
PU: Most applicable to the food industry and other industries .
Subsequent machining technology:
it can add baffle, skirt, sponge, guide bar and etc.
Conveyor belt fabric layers:
A layer of cloth and a layer of glue, two layers of cloth and two
layers of glue, three layers of cloth and three layers of glue, and
so on. It can be customized according to your requirements.
Colors:
Red, yellow, green, blue, gray, white, black, blue, green,
transparent (in general we have)
Thickness:
PVC (1~7mm) PU (1~8mm)
Appearance:
flat surface, diamond pattern, lawn pattern, golf pattern etc.
Advantages:
PVC: economical and practical, technology is mature. Non-toxic,
odorless, environmentally friendly.
PU: abrasion resistant and corrosion.
| Belt code | Top cover | Bottom cover |
| Material | Color | Thckness | Pattern | Hardness sh(A) | Color | Pattern |
| 11PUMJ 1.05 | PU | green | 0.5 | fabric | 90 | | |
| 12PU 0.8 | PU | white | 0.2 | smooth | 90 | | |
| 14PUDD0.75 | PU | Black | 0.5 | tape | 80 | green | cotton |
| 22PU1.4 | PU | white | 0.2 | smooth | 90 | | |
| 22PU1.5S | PU | white | 0.5 | smooth | 90 | | |
| 22PU2 | PU | white | 0.5 | smooth | 90 | | |
| 22PUS1.8 | PU | white | 1.5 | diamond | 90 | | |
| 22PUV1.5 | PU | Sky bule | 0.7 | matt | 90 | | |
| 31PUCB3.5 | PU | green | 3 | Mini-grip | 90 | | |
| 33PUS3.2 | PU | Petrol green | 1 | diamond | 90 | | |
| 11C4 | PVC | green | 3.5 | Rough top | 75 | | |
| 11P1 | PVC | green | 0.4 | smooth | 75 | | |
| 11QB5 | PVC | green | 2.4 | smooth | 70 | green | smooth |
| 11S1 | PVC | green | 0.4 | diamond | 75 | | |
| 12D1.8/MD | PVC | white | 0.9 | golf | 75 | | cotton |
| 12P1 | PVC | white | 0.4 | smooth | 65 | | |
| 12P1.5/MD | PVC | white | 0.7 | smooth | 75 | | cotton |
| 15MJ0.9 | PVC | grey | 0.5 | majiang | 75 | grey | |
| 17WB1 | PVC | Dark green | 0.1 | Fabric patten | 70 | Dark green | Fabric patten |
| 210P2 | PVC | green | 0.5 | smooth | 75 | | |
| 21BC5 | PVC | green | 3.5 | Wave rough top | 60 | | |
Belt code |
No.ofplies |
Belt Thick mm |
weight | Breaking load | Woring load at 1% | Minimum pulley | Max roll
|
Notes |
| Kg/m2 | M/mm | Elongation N/M | Diameter mm | Width mm |
| 11PUMJ 1.05 | 1 | 1.05 | 1.2 | >=50 | >=4 | 10 | 2100 | |
| 12PU 0.8 | 1 | 0.8 | 1 | >=100 | >=8 | 10 | 3000 | |
| 14PUDD0.75 | 1 | 0.75 | 0.9 | >=50 | >=4 | 10 | 1750 | |
| 22PU1.4 | 2 | 1.4 | 1.7 | >=100 | >=8 | 20 | 3000 | |
| 22PU1.5S | 2 | 1.5 | 1.8 | >=100 | >=8 | 3 | 3000 | Flexible fabric |
| 22PU2 | 2 | 2 | 2.5 | >=100 | >=8 | 30 | 3000 | |
| 22PUS1.8 | 2 | 1.8 | 1.8 | >=100 | >=8 | 60 | 3000 | |
| 22PUV1.5 | 2 | 7.5 | 1.8 | >=100 | >=8 | 30 | 3000 | |
| 31PUCB3.5 | 3 | 3.5 | 3.96 | >=100 | >=15 | 60 | 2000 | |
| 33PUS3.2 | 3 | 3.2 | 3.72 | >=150 | >=12 | 60 | 3000 | |
| 11C4 | 1 | 4 | 3.44 | >=50 | >=4 | 40 | 3000 | |
| 11P1 | 1 | 1 | 1.1 | >=50 | >=4 | 20 | 3000 | |
| 11QB5 | 1 | 5 | 5.2 | >=80 | >=6 | | 3000 | Side wall |
| 11S1 | 1 | 1 | 1.1 | >=50 | >=4 | 20 | 3000 | |
| 12D1.8/MD | 1 | 1.5 | 1.3 | >=80 | >=5 | 40 | 3000 | |
| 12P1 | 1 | 1 | 1.1 | >=50 | >=4 | 20 | 3000 | |
| 12P1.5/MD | 1 | 1.5 | 1.3 | >=80 | >=5 | 40 | 3000 | |
| 15MJ0.9 | 1 | 0.9 | 1.08 | >=40 | >=3 | 10 | 2000 | |
| 17WB1 | 1 | 1 | 1.1 | >=50 | >=6 | 40 | 3000 | |
| 210P2 | 2 | 2 | 4.56 | >=100 | >=8 | 40 | 2000 | |
| 21BC5 | 2 | 5 | 5.25 | >=100 | >=8 | 60 | 2000 | |
“Good quality and good service always makes customer happy”
Our company
wuxi Robert Industrial belt Co., Ltd.was established in May 2011
year , my company of "Good quality and good service always makes
customer happy" principle, provide customers with quality and
quantity of various types of products. Always uphold the "quality,
integrity and pragmatic, motivated, service-oriented" business
philosophy, and applies the company's management and operating
among.
2014 year Products are sold to foreign markets, and is very popular
in the customer market. And our company has many famous enterprises
at home and abroad to establish a long-term friendly business
relationship.
We began producing PU timing belts.Rubber V belt, and other new
products
We have introduced advanced production lines. Our company area
increased to 130,000 square meters, we have 90 employees.
2017 year continue to improve product quality,Develop new markets
FAQ
Q: Are you trading company or manufacturer ?
A: We are factory.
Q: How long is your delivery time?
A: Generally it is 5-10 days if the goods are in stock. or it is
15-20 days if the goods are not in stock, it is according to
quantity.
Q: Do you provide samples ? is it free or extra ?
A: Yes, we could offer the sample for free charge but do not pay
the cost of freight.
Q: What is your terms of payment ?
A: Payment<=1000USD, 100% in advance. Payment>=1000USD, 30%
T/T in advance ,balance before shippment.
If you have another question, pls feel free to contact us
